KVM-switch - ATEN 16-Port USB True 4K DisplayPort KVM Switch wi - CS19216-AT-G
Varenummer: 3021130
CS19216-AT-G
CS19216-AT-G
CS19216-AT-G
CS19216-AT-G
CS19216-AT-G

ATEN 16-Port USB True 4K DisplayPort KVM Switch wi

KVM / lyd / USB-svitsj, 16 x KVM/lyd/USB, 1 lokalbruker, stasjonær, rackmonterbar

26 770,00 kr 21 416,00 kr eksl. mva
Gratis frakt (privatkunde)
Fjernlager, 6-8 dager til forsendelse

The ATEN CS19216 16-port USB 3.0 4K DisplayPort KVM switch can effectively access and control up to 16 DisplayPort computers from a single USB keyboard, USB mouse, and monitor console. With its dual interface console, users can choose between DisplayPort/HDMI video output supporting high video quality up to 4K DCI (4096 x 2160 @ 60Hz), presenting crystal-clear visuals.To meet the needs of easy expansion and flexibility, the CS19216 can be cascaded to two levels to control up to 256 computers from a single console. Furthermore, the CS19216 supports multi-display function by stacking up to eight CS19216 units to compare and analyze information on 8 monitors at most, which substantially streamlines the working environment.With two patented ATEN technology - Video DynaSync and EDID Expert, the CS19216 can optimize display resolution, accelerate switching between ports and power up smoothly while eliminating boot-up display problems.Besides, the CS19216 comes with a built-in USB 3.1 Gen 1 hub delivering data transfer rates up to 5 Gbps, allowing users to speed up operations and share USB peripherals instantly. For user-friendly port selection methods, the C19216 offers pushbuttons, hotkeys, RS-232 commands, and OSD with UI, bringing effortless and intuitive operations.

Produsent
Varenummer
3021130
Model
CS19216-AT-G
Ean
4719264649264
Til produsentens hjemmeside
Produktbeskrivelse
ATEN CS19216 - KVM / lyd / USB-svitsj - 16 porter - rackmonterbar
Enhetstype
KVM / lyd / USB-svitsj - 16 porter - kaskademulighet
Utførelse
Rackmonterbar
Undertype
DisplayPort
Porter
16 x KVM/lyd/USB
Antall KVM-brukere
1 lokalbruker
Egenskaper
Oppgraderbar fastvare, metallhus, EDID Expert, passordvern
Tilpassede standarder
USB 3.1 Gen 1
Strømforsyning
DC 12 V
Dimensjoner (BxDxH)
43.24 cm x 21.43 cm x 4.4 cm
Vekt
3.54 kg

Generelt

Enhetstype
KVM / lyd / USB-svitsj - 16 porter - kaskademulighet
Utførelse
Stasjonær, rackmonterbar
Undertype
DisplayPort
Porter
16 x KVM/lyd/USB
Antall lokale KVM-brukere
1 lokalbruker
Tastatur/mus-grensesnitt
USB
Maks. oppløsning
4096 x 2160 @ 60 Hz
Egenskaper
Oppgraderbar fastvare, metallhus, EDID Expert, passordvern, kringkastingsmodus, ATEN Video DynaSync, Auto Scan-modus
Tilpassede standarder
USB 3.1 Gen 1
Innebygde enheter
2-ports USB 3.1 Gen 1-hub
Statusindikatorer
Strøm, velg, USB, online

Ekspansjon / Tilkoplinger

Grensesnitt
1 x tastatur (USB) Type A konsoll
1 x mus (USB) Type A konsoll
1 x DisplayPort konsoll
1 x HDMI konsoll
2 x lyd minijakk konsoll
16 x DisplayPort
16 x USB 3.1 Gen 1 Type B
16 x lyd minijakk
1 x styring RJ-11
2 x USB 3.1 Gen 1 Type A

Strømforsyning

Strømenhet
Ekstern strømadapter
Påkrevd nettspenning
DC 12 V
Strømforbruk ved drift
26.66 watt

Diverse

Medfølgende kabler
2 x DisplayPort-kabel
2 x SuperSpeed USB-kabel
2 x lydkabel
1 x fastvareoppgraderingskabel
Rack-monteringssett
Inkludert
Tilpassede standarder
RoHS, DisplayPort 1.4, HDCP 2.2

Mål og vekt

Bredde
43.24 cm
Dybde
21.43 cm
Høyde
4.4 cm
Vekt
3.54 kg
