Komponenter for switchboxes og skap - Hager Contactor 40a 4no 230v 3m - ESC440

Varenummer: 2892497

Hager Contactor 40a 4no 230v 3m

Name: Hager Contactor 40a 4no 230v 3m
Brand: Hager
SKU: 2892497
Price: 1598.00 NOK
Availability: InStock

Contactor 40A 4NO 230V Standard for the control of circuitsCan be equipped with auxiliary contact and sealig capsRated operational voltage: 400 V AC control voltage: 230V Frequency: 50/60Hz Type of connection: With screw Operating temperature: -10 to 50 ° C Storage temperature: -40 to 80 ° C Connection cross-sect rigid cable: 4 / 25mm2 Connection cross-sect. flexible cable: 4 / 16mm2 To reduce the mutual heating when using several contactorsit is recommended to use the LZ060 spacerNumber of modules: 3According to standard: EN 61095

Les mer

1 598,00 kr 1 278,40 kr eksl. mva

Gratis frakt (privatkunde)

Fjernlager, 2-4 dager til forsendelse

UTVIDET JULERETURRETT FRAM TIL 31. JANUAR 2025

Proshop tilbyr utvidet Juleretur til privatkunder på ordre kjøpt i perioden 1. november til 23. desember 2024. Les betingelsene her.

Contactor 40A 4NO 230V 3M Product Description: Contactor rated at 40A with four normally open contacts and a voltage rating of 230V. Suitable for controlling and switching lighting systems and heating in residential and office environments. Rated voltage: 400V, frequency:50/60Hz. Operating category: AC1 Number of operations:1,000,000 Operating temperature range:-10 to +50°C Connection type:solid wire (4-25mm2) or flexible wire (4-16mm2). Width is three modules at a size of17.5mm each.

Produsent

Hager

Varenummer

2892497

Model

ESC440

Ean

3250612401284

Til produsentens hjemmeside

hager.com/

Antall poler

Nåværende kontaktkapasitet

40 A

Antall kontakter

Kabel del

4/16 mm²

AC-inngangsspenning

230 V

AC-inngangsfrekvens

50 Hz

Driftstemperatur (T-T)

-10 - 50 °C

Samsvarssertifikat

RoHS

Egenskaper
