Komponenter for switchboxes og skap - Hager Humfree contactor 40a 4no 230v 3m - ESC440S
Varenummer: 2748802

Hager Humfree contactor 40a 4no 230v 3m

Humfree contactor 40A 4NO 230V Humfree for the control of circuitsGuarenteed silence during the entire life of the productCan be equipped with auxiliary contact and sealig capsRated operational voltage: 400 V Frequency: 50/60Hz Type of connection: With screw Operating temperature: -10 to 50 ° C Storage temperature: -40 to 80 ° C Connection cross-sect rigid cable: 4 / 25mm2 Connection cross-sect. flexible cable: 4 / 16mm2 To reduce the mutual heating when using several contactorsit is recommended to use the LZ060 spacerNumber of modules: 3According to standard: EN 61095

Les mer
1 737,00 kr 1 389,60 kr eksl. mva
Gratis frakt (privatkunde)
Fjernlager, 2-4 dager til forsendelse

Contactor 40A 4 NO 230VAC noiselessProduct description: Contactor 40A with four normally open contacts, suitable for controlling and switching lighting systems and heating in residential and office environments where noiseless operation is desired. Rated voltage: 400V 50/60Hz. Operating category: AC1. Number of switches: 1,000,000. Operating temperature range: -10 to +50°C. Connection type: solid wire from 4-25mm2 / flexible wire from 4-16mm2.Width: three modules at a width of17.5mm each.

Produsent
Varenummer
2748802
Model
ESC440S
Ean
3250612400409
AC-inngangsspenning
400 V
Samsvarssertifikat
RoHS
Antall
1

Energihåndtering

AC-inngangsspenning
400 V

Tekniske detaljer

Samsvarssertifikat
RoHS

Emballasjeinnhold

Antall
1
