Komponenter for switchboxes og skap - Hager Latching relay 1no 24v - EPN513
Varenummer: 2764759

Hager Latching relay 1no 24v

Latching relay 1NO 24VFor pulse control of light installations.Rated current In: 16A AC1Rated Voltage Un: 230VACVoltage Voltage Un: 2 4VAC / 12VDCPulse Length: min. 50ms and max 1 hourPower consumption v. AC operation: 24VATouch protection: IP20Connection: 0.75 - 10mm2Dimensions: 1 module of 17.5mmStandard: EN 60669-1 / 2-2Note: Operating pressure must be selected in h.t. Attraction consumption, as well as lead length and dimension must be observed. See technical data in catalog.

Les mer
316,00 kr 252,80 kr eksl. mva
Rimeligste private frakt: 99,00 kr
Fjernlager, 2-4 dager til forsendelse

Relay switch 16A 24V 1 pole Product description: Relay switch EPN513 16A 24V 1 pole for impulse control of lighting installations. Rated current In: 16A AC1 Rated voltage Un:230VAC Coil voltage Un:24VAC/12VDC Pulse length: min.50ms and max.1 hour Power consumption at AC operation:24VA Touch protection rating IP20 Connection size range :0,75 -10mm2 Dimensions :1 module at17,5mm Standard EN60669-1/2-2 Note:The operating pressure must be selected according to the power consumption, and the wire length and dimension must be observed. See technical data in catalog.

Produsent
Varenummer
2764759
Model
EPN513
Ean
3250612369584
AC-inngangsspenning
250 V
Samsvarssertifikat
RoHS
Antall
1

Energihåndtering

AC-inngangsspenning
250 V

Tekniske detaljer

Samsvarssertifikat
RoHS

Emballasjeinnhold

Antall
1
