Komponenter for switchboxes og skap - Hager Latching relay 4no 230v - EPN540
Varenummer: 2764751

Hager Latching relay 4no 230v

Latching relay 4NO 230VFor pulse control of light installations.Rated current In: 16A AC1Rated Voltage Un: 230 / 400VACVoltage Voltage Un: 230VAC / 110VDCPulse Length: min. 50ms and max 1 hourPower consumption v. AC operation: 48VATouch protection: IP20Connection: 0.75 - 10mm2Dimensions: 1 module of 17.5mmStandard: EN 60669-1 / 2-2Note: Operating pressure must be selected in h.t. Attraction consumption, as well as lead length and dimension must be observed. See technical data in catalog.

Les mer
1 284,00 kr 1 027,20 kr eksl. mva
Gratis frakt (privatkunde)
Fjernlager, 2-4 dager til forsendelse

Relay switch 16A 250V 4-pole single throw, for impulse control of lighting installations. Rated current In: 16A AC1. Rated voltage Un: 230/400VAC. Coil voltage Un: 230VAC/110VDC. Pulse length: minimum of 50ms and maximum of one hour. Power consumption at AC operation: 48VA. Protection rating: IP20. Connection size range from .75 to10mm2, dimensions are one module at17,5mm according to EN60669-1/2-2 standards.Bear in mind that the operating pressure must be selected according to the power consumption and wire length and dimension must be observed as per technical data in catalogues provided by manufacturer

Produsent
Varenummer
2764751
Model
EPN540
Ean
3250612369454
AC-inngangsspenning
250 - 400 V
Samsvarssertifikat
RoHS
Antall
1

Energihåndtering

AC-inngangsspenning
250 - 400 V

Tekniske detaljer

Samsvarssertifikat
RoHS

Emballasjeinnhold

Antall
1
