Komponenter for switchboxes og skap - Hager Rcbo 1p+n 6ka b-10a 30ma a - ADA910G
Varenummer: 2764824

Hager Rcbo 1p+n 6ka b-10a 30ma a

RCBO 1P+N 6kA B-10A 30mA ATechnical data:Release curve: BPoles: 2 poles.Nominal load (in): 10 ARated Voltage (Un): 230V + 10% / -15%Rated output current (Idn): 30mASensitivity Class AFrequency: 50HzRated breakdown: 6kA in h.t. EN61009-1IP protection: IP2x mounted in enclosure.Temperature: 30 ° C in h.t. EN61009-Pollution rate: 2 in h.t. EN61009-1

Les mer
1 218,00 kr 974,40 kr eksl. mva
Gratis frakt (privatkunde)
Fjernlager, 2-4 dager til forsendelse
proshop-xmas-gran proshop-xmas-gran

UTVIDET JULERETURRETT FRAM TIL 31. JANUAR 2025

Proshop tilbyr utvidet Juleretur til privatkunder på ordre kjøpt i perioden 1. november til 23. desember 2024. Les betingelsene her.

HPFI / circuit breaker combo 1P+N 10AProduct description: HPFI ADA910G / circuit breaker combo. 1P+N 10A. The combo-circuit breaker is a compact unit that ensures protection against overload, short circuit, and ground fault. It protects people and animals from electric shock in residential and commercial buildings. It also protects property from fire in case of insulation failure.Technical data:Trip curve: BPoles: 2 poles.The neutral is located on the right side.Rated current (In): 10 ARated voltage (Un): 230V +10%/-15%Nominal tripping current (Idn): 30mASensitivity Class AFrequency:50Hz Nominal breaking capacity:6kA according to EN61009-1 IP protection class : IP2x mounted in enclosure.Temperature :30°C according to EN61009-1 Pollution degree :2 according to EN61009-1 The combo-circuit breakers are all with one pole and neutral - in a two-module width (36mm).Technical specifications:Current rating(A) :10 Trip curve:B Number of poles:1P+N Fault tripping current(mA) :30

Produsent
Varenummer
2764824
Model
ADA910G
Ean
3250611010975
