Hager Rcbo 1p+n 6ka c-10a 300ma a
RCBO 1P+N 6kA C-10A 300mA ATechnical data:Release curve: CPoles: 2 poles.Nominal load (in): 10 ARated Voltage (Un): 230V + 10% / -15%Rated output current (Idn): 300mASensitivity: Class AFrequency: 50HzRated breakdown: 6kA in h.t. EN61009-1IP protection: IP2x mounted in enclosure.Temperature: 30 ° C in h.t. EN61009-1Pollution rate: 2 in h.t. EN61009-1
2 838,00 kr
2 270,40 kr eksl. mva
Gratis frakt (privatkunde)
Fjernlager, 2-4 dager til forsendelse
PFI AFA960G / Circuit breaker combo 1P+N 10A/C Product description: PFI AFA960G / Circuit breaker combo. 1P+N 10A/C The combo circuit breaker is a compact unit that ensures protection against overload, short circuit and ground fault. It protects people and animals from electric shock in residential and commercial buildings. It protects property from fire in case of insulation failure.Technical data:Trip curve: C Poles: 2 poles.The neutral is located on the right side.Rated current (In): 10 ARated voltage (Un): 230V +10%/-15%Rated tripping current (Idn): 300mASensitivity: Class AFrequency:50Hz Rated breaking capacity :6kA according to EN61009-1IP protection : IP2x mounted in enclosure.Temperature :30°C according to EN61009-1Pollution degree :2 according to EN61009-1The combo breakers are all with one pole and neutral - in a width of two modules (36mm) Technical specifications: Rated current(A) :10Trip curve:CNumber of poles :1P+NFault tripping current(mA) :300
