Komponenter for switchboxes og skap - Hager Rcbo 1p+n 6ka c-13a 30ma a - ADA963G
Varenummer: 2764821

Hager Rcbo 1p+n 6ka c-13a 30ma a

RCBO 1P+N 6kA C-13A 30mA ATechnical data:Release curve: CPoles: 2 poles.Nominal load (in): 13 ARated Voltage (Un): 230V + 10% / -15%Rated output current (Idn): 30mASensitivity Class AFrequency: 50HzRated breakdown: 6kA in h.t. EN61009-1IP protection: IP2x mounted in enclosure.Temperature: 30 ° C in h.t. EN61009-1Pollution rate: 2 in h.t. EN61009-1

Les mer
769,00 kr 615,20 kr eksl. mva
Rimeligste private frakt: 99,00 kr
Fjernlager, 2-5 dager til forsendelse
proshop-xmas-gran proshop-xmas-gran

UTVIDET JULERETURRETT FRAM TIL 31. JANUAR 2025

Proshop tilbyr utvidet Juleretur til privatkunder på ordre kjøpt i perioden 1. november til 23. desember 2024. Les betingelsene her.

HPFI / Circuit breaker combination 1P+N 13A/C Product description: HPFI ADA963G / Circuit breaker combination. 1P+N 13A/C The combination circuit breaker is a compact unit that ensures protection against overload, short circuit and ground fault. It protects people and animals from electric shock in residential and commercial buildings. It protects property from fire in case of insulation failure.Technical data:Trip curve: C Poles: 2 poles.The neutral is located on the right side.Rated current (In): 13 ARated voltage (Un): 230V +10%/-15%Rated tripping current (Idn): 30mASensitivity Class AFrequency:50Hz Rated breaking capacity :6kA according to EN61009-1IP protection : IP2x mounted in enclosure.Temperature :30°C according to EN61009-1Pollution degree :2 according to EN61009-1The combination circuit breakers are all with one pole and neutral - in a width of two modules (36mm) Technical specifications: Rated current(A) :13 Trip curve:C Number of poles:1P+NGround fault trip current(mA) :30

Produsent
Varenummer
2764821
Model
ADA963G
Ean
3250611011088
