Komponenter for switchboxes og skap - Schneider Electric Tesys d contactor lc1d12p7 3p 12a ac-3 5.5kw@400v 1no+1nc - LC1D12P7
Varenummer: 2758672

Schneider Electric Tesys d contactor lc1d12p7 3p 12a ac-3 5.5kw@400v 1no+1nc

LC1D12P7 is a 3-pole TeSys D contactor from Schneider Electric for motor applications up to 5.5kW@400V. It includes a 230V 50/60Hz AC coil and 1NO+1NC built-in auxiliary contacts, it can be used in safety applications thanks to its certified NC mirror contact. Compact, DIN-rail mounting, it procures high reliability and durability. Available worldwide, it is multi-standards certified (IEC, UL, CSA, CCC, EAC, Marine) and Green Premium compliant (RoHs/Reach). Compact product, 45mm wide, for DIN-rail and panel mounting. Clear separation between power and control circuits, easy front access to coil and auxiliary contacts connections . Equipped with a 230V AC coil that can be supplied at 50Hz or 60Hz. Provides 2 built-in auxiliary contacts 1NO + 1NC, NC is a certified mirror contact suitable to be included in the control of safety systems. High electrical durability, guaranteed for 2 million cycles at 12A AC-3 440V, for demanding motor switching applications. Robust design with high making and breaking capacities up to 20 In. Connections by screw clamp terminals

Les mer
538,00 kr 430,40 kr eksl. mva
Rimeligste private frakt: 99,00 kr
Fjernlager, 3-6 dager til forsendelse
proshop-xmas-gran proshop-xmas-gran

UTVIDET JULERETURRETT FRAM TIL 31. JANUAR 2025

Proshop tilbyr utvidet Juleretur til privatkunder på ordre kjøpt i perioden 1. november til 23. desember 2024. Les betingelsene her.

TeSys D contactor LC1D12P7, 3P 12A AC-3 5.5kW@400V, 1NO+1NC auxiliary contact, 230V 50/60Hz AC coil. Product description: TeSys D contactor for connecting motors with loads in application category AC-3. Rated current up to 12A. The LC1D12P7 contactor is compact and easy to integrate into all types of applications such as industry, infrastructure and buildings. The unit is quickly mounted with clips directly on DIN rail. Technical specifications: Terminals: screws Rated current at 440V AC3: ​​12A Coil: 230V AC

Produsent
Varenummer
2758672
Model
LC1D12P7
Ean
3389110349306
Til produsentens hjemmeside
Produktfarge
Flerfarget
AC kontakt rangering
230 AC

Egenskaper

Produktfarge
Flerfarget
AC kontakt rangering
230 AC
