Shelly Pro Dimmer 0/1-10V PM

Shelly Pro Dimmer 0/1-10V PM is a WiFi-controlled 0/1-10V controller. The device is designed for controlling lighting, motors, valves, and similar applications. Shelly Pro Dimmer 0/1-10V PM operates in sourcing mode, meaning it generates its own 1-10V signal. The device also has a built-in relay for cut-off and power metering. Shelly Pro Dimmer 0/1-10V PM is easily set up and controlled through the Shelly Smart Control app or your preferred Smart Home or Smart Building system. Shelly devices work 100% locally and only require a local network to operate. Shelly can be used alone in the Shelly Smart Control app or with more than 200 partner systems such as Google Home, Amazon Alexa, Home Assistant, Samsung SmartThings, Athom Homey, KNX, and many more. Function Shelly Pro Dimmer 0/1-10V PM is primarily used for controlling 1-10V ballasts for lighting but is also suitable for regulating the speed of fans, motors, and similar devices. The device has two inputs for standard single-pole switches with and without spring return, allowing control via one- and two-button operation. The device supports night mode, so the light can automatically turn on at a lower brightness level at night. It is also possible to set minimum and maximum brightness, dimming speed, auto on/off timers, and much more. Connection Shelly Pro Dimmer 0/1-10V PM can connect to the internet or the local network through a LAN interface and/or 2.4 GHz WiFi. Additionally, the device has built-in Bluetooth like the rest of the Pro, Plus, and Gen3 devices, so it can also be used as a gateway for Shelly Bluetooth devices. The device works locally without connection to Shelly Cloud, but it is recommended to activate it for easy data storage and increased functionality. The device can also communicate via MQTT, HTTP, and WebSocket. All support TLS. Hardware The device is equipped with generation 2 hardware, which includes a powerful ESP32 processor. This allows for scripting functions for advanced and customized functionality as well as a range extender function with the device.
