Switch/splitter - TRENDnet TPE-3524SF - switch - 52-port web - 52 ports - smart - rack-mountable - TAA Compliant - TPE-3524SF
Varenummer: 3238103
TPE-3524SF
TPE-3524SF

TRENDnet TPE-3524SF - switch - 52-port web - 52 ports - smart - rack-mountable - TAA Compliant

Switch, 52-port, web, L2+, smart, 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+, stasjonær, rackmonterbar, PoE+ (740 W), TAA-samsvar

9 025,00 kr 7 220,00 kr eksl. mva
Gratis frakt (privatkunde)
Fjernlager, 3-5 dager til forsendelse

TRENDnet's 52-Port Gigabit Web Smart PoE+ Switch with 10G SFP+ ports, model TPE-3524SF, offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of SMB networks. This managed PoE+ switch with SFP+ ports comes with an intuitive web-based interface. Advanced managed switch features include LACP to group ports together to increase bandwidth between switches, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this a powerful solution for SMB networks. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with the easy-to-use voice VLAN feature.Free up router resources by offloading routing processes to the managed switch by using the L2+ Managed IPv4/IPv6 static routing feature to efficiently route traffic at the switch level. The dynamic ARP inspection feature helps protect connected devices from man-in-the-middle attacks by discarding malicious and invalid ARP packets. Take advantage of the available multicast and IGMP/MLD snooping features to optimize IP surveillance system performance, and minimize network traffic. This TRENDnet Web Smart Managed PoE+ Switch also features 10G SFP+ ports to support long-distance fiber networking applications.Installers and integrators can save on equipment costs and reduce installation time with TRENDnet's Web Smart Managed PoE+ Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables. With PoE technology, users only need one set of cables to deliver both data and power. With this PoE+ managed switch, network PoE devices such as high-power wireless access points, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.

Produsent
Varenummer
3238103
Model
TPE-3524SF
Ean
0710931162523
Til produsentens hjemmeside
Produktbeskrivelse
TRENDnet TPE-3524SF - switch - 52-port, web - 52 porter - smart - rackmonterbar - TAA-samsvar
Enhetstype
Switch - 52 porter - L2+ - smart
Utførelse
Rackmonterbar 1U
Undertype
Gigabit Ethernet
Porter
48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+
Strøm via Ethernet (PoE)
PoE+
PoE-budsjett
740 W
Ytelse
Koblingskapasitet: 176 Gbps
Videresendingsytelse (64-bytepakkestørrelse): 130.95 Mpps
Kapasitet
VLAN-grupper: 256
ARP-bord: opptil 128
Mac Adress Tabellstørrelse
32K innganger
Jumborammestøtte
9KB
Protokoll for fjernstyrt administrasjon
SNMP 1, RMON 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH-2
Egenskaper
DHCP-støtte, VLAN støttet, IGMP-snusing, IPv6-støtte, full dupleksmodus, DHCP-snusing, QoS, MLD-snusing, overspenningsvern, kortslutningsvern, GVRP, statisk ruting, SP, DoS, båndbreddekontroll per port, støtte for DSCP, dobbel bildestøtte, Static Link Aggregation, Voice VLAN, Private VLAN, IGMP--hurtigutgang, Inter-VLAN Routing, WRR, loopback-påvisning, blokkere ukjent multicast, nettbasert styring, Smart Fans, MAC-Port Binding, LLDP-MED, HoL Blocking Prevention
Tilpassede standarder
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
Strømforsyning
AC 100-240 V (50/60 Hz)
Dimensjoner (BxDxH)
44 cm x 31 cm x 4.4 cm
Vekt
4.725 kg
TAA-samsvar
Ja
Fabrikantgaranti
Begrenset livstidsgaranti

Generelt

Enhetstype
Switch - 52 porter - L2+ - smart
Utførelse
Stasjonær, rackmonterbar 1U
Undertype
Gigabit Ethernet
Porter
48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+
Strøm via Ethernet (PoE)
PoE+
PoE-budsjett
740 W
Ytelse
Koblingskapasitet: 176 Gbps
Videresendingsytelse (64-bytepakkestørrelse): 130.95 Mpps
Kapasitet
VLAN-grupper: 256
ARP-bord: opptil 128
Mac Adress Tabellstørrelse
32K innganger
Jumborammestøtte
9KB
Protokoll for fjernstyrt administrasjon
SNMP 1, RMON 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH-2
Krypteringsalgoritme
TLS, SSL 3.0, SSL 2.0
Autentifikasjons Metode
RADIUS, TACACS+
Egenskaper
DHCP-støtte, VLAN støttet, IGMP-snusing, IPv6-støtte, full dupleksmodus, DHCP-snusing, QoS, MLD-snusing, overspenningsvern, kortslutningsvern, GVRP, statisk ruting, SP, DoS, båndbreddekontroll per port, støtte for DSCP, dobbel bildestøtte, Static Link Aggregation, Voice VLAN, Private VLAN, IGMP--hurtigutgang, Inter-VLAN Routing, WRR, loopback-påvisning, blokkere ukjent multicast, nettbasert styring, Smart Fans, MAC-Port Binding, LLDP-MED, HoL Blocking Prevention
Tilpassede standarder
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
Innebygde enheter
3 x vifter
Statusindikatorer
Status

Ekspansjon / Tilkoplinger

Grensesnitt
48 x 1000Base-T RJ-45 PoE+ - 30 W
4 x 10 Gbit-LAN SFP+
1 x konsoll RJ-45

Strømforsyning

Strømenhet
Intern strømforsyning
Påkrevd nettspenning
AC 100-240 V (50/60 Hz)

Diverse

Tilleggsutstyr inkludert
Strømkabel (1,5 m)
Medfølgende kabler
1 x konsollkabel - 1 m
Rack-monteringssett
Inkludert
MTBF
70,599 timer
Tilpassede standarder
UL, FCC, NDAA
TAA-samsvar
Ja

Mål og vekt

Bredde
44 cm
Dybde
31 cm
Høyde
4.4 cm
Vekt
4.725 kg
